Dimensions:
Height: 23.62 In
Width: 18.03 In
Thickness: 1.02 In
Feature:
Our products are brand new and quality inspected
Tank Material: Plastic
Core Material: Aluminum
Note: Without Sensor Port
Fits Vehicles of the Following Years and Make:
2008-2013 BMW 128i 3.0L
2008-2009 BMW 135i 3.0L
2006 BMW 325Ci 2.5L
2006 BMW 325i 2.5L
2006 BMW 325i 3.0L
2006 BMW 325xi 3.0L
2012 BMW 328i 2.0L
2007-2013 BMW 328i 3.0L
2009-2012 BMW 328i xDrive 3.0L
2007-2008 BMW 328xi 3.0L
2006 BMW 330Ci 3.0L
2006 BMW 330xi 3.0L
2010-2011 BMW Z4 3.0L
Function:
The function of the cooling system is to radiate excess and useless heat from the engine, so that the engine can maintain normal temperature operation at various speeds or driving conditions
Leakage Treatment:
When the leak does not exceed 1mm cracks or 2mm holes, add a bottle of water tank strong plugging agent to the water tank to start the car
If there is no anti-leak agent to carry, the individual radiator pipes slightly leak water, you can temporarily put the loose tobacco into the water tank, and use the water circulation pressure to block the tobacco in the leaking part of the radiator pipe for temporary use
If the water tank radiator pipe leaks more seriously, you can cut the leaking radiator pipe from the leaking place, block the cut radiator pipe with a cotton ball coated with soap, and then use pliers to flatten the head of the cut radiator pipe and then crimp it. Press tightly to stop water leakage
If the rubber pipe joint is leaking, you can use a screwdriver to wrap the rubber pipe joint clamp twice on the rubber pipe joint in time, and then tighten it with pliers. If the rubber tube is damaged, tape the broken place tightly and use it temporarily
Steps to Replace the Car Radiator:
Step 1
Remove the wire harness clip inside the beam on the upper part of the water tank, and remove the wire harness
Step 2
Disassemble the air filter assembly and remove the control computer
Step 3
Remove the headlight on the right
Step 4
Remove the fan frame assembly
Step 5
Unscrew the drain bolt at the bottom of the water tank and collect the coolant
Step 6
Disassemble the upper and lower water pipes
Step 7
Remove the fixing bolts of the water tank
Step 8
Take out the water tank at a certain angle and reinstall it in the reverse step
How to clean the Radiator?
1. Open and secure the engine cover firmly to avoid accidental sliding. Then, use a nylon brush and soapy water to gently wipe the dead insects and debris collected on the water tank grille
2. Be sure to scrub in the direction of the water tank fins, do not scrub in the opposite direction, because the metal is fragile and easy to bend and deform. After cleaning the grille, draw a gentle stream of water from the hose above the grille to ensure that all debris has been completely removed
Item Specifics
Brand: auspartshouse
Manufacturer Part Number: 9868443
Type: Radiator
Material: Aluminum
Row Count: 1 Row
Fitment Type: Direct Replacement
Color: Silver
Quantity: 1
Manufacturer Warranty: 1 Year
Quantity Sold: Sold Individually
Condition: Brand New
Feature: High Quality
Interchange Part Number: 2882, 17117562079
Other Part Number: BM3000147
Custom Bundle: No
Modified Item: No
Core Width: 18.03 In
Core Height: 23.62 In
Core Thickness: 1.02 In
Superseded Part Number: 171175679
